progeCAD Professional
progeCAD is professional architectural CAD software that runs the same DWG files and commands as AutoCAD — for a one-time price with no annual subscription. The AEC Architectural module with intelligent building objects is included free.
All the 2D drafting tools architects rely on — dimensioning, hatching, section markers, elevation callouts, and title blocks. Compatible with every DWG file from AutoCAD Architecture without conversion.
Intelligent AEC walls, doors, windows, stairs, roofs, and slabs — included at no extra cost. Walls join automatically at corners. Doors and windows cut openings when placed. Build 2D and 3D building models from smart AEC objects.
Import Autodesk Revit (.rvt, .rfa) and IFC files directly into progeCAD. Work with BIM models from architects and structural engineers — extract geometry, reference in drawings, or flatten into 2D documentation.
Import PDFs as editable DWG geometry with layers intact. Export drawings to PDF with full layer, lineweight, and pen table control.
Free block library covering furniture, fixtures, doors, windows, plumbing, kitchen equipment, landscaping, accessibility symbols, and more — ready to drop into floor plans and elevations.
Open, edit, and share DWG files from AutoCAD 2.5 through the latest version. Send drawings to consultants and contractors on AutoCAD Architecture with no conversion, no rework, no data loss.
Attach structural, MEP, and civil drawings as external references — each discipline works in their own file while you see the full coordinated set. Xrefs update automatically when the source file changes.
Automate repetitive tasks — room labels, title block population, standard detail insertion, and layer setup. Most existing AutoCAD Lisp routines run without modification.
Manage multi-sheet drawing sets — coordinate drawing numbers, revision tracking, and sheet indexes across an entire project. Compatible with AutoCAD Sheet Sets.
AEC Architectural Module
The AEC Architectural module gives progeCAD intelligent building objects that behave the way architects expect — walls that join at corners, doors and windows that cut openings automatically, and roofs that generate from wall footprints.
Draw walls by clicking start and end points. Walls automatically clean up at corners, T-junctions, and intersections. Set width, height, base offset, and layer assignment. Walls update in both 2D plan and 3D model simultaneously.
Insert doors and windows into walls — the opening is cut automatically in plan and 3D. Choose from standard types and sizes, set swing direction, set sill height and head height. Drag to reposition along the wall.
Generate roof planes from wall footprints — hip, gable, shed, and complex roof forms. Define pitch, overhang, and fascia. Slabs for floors and ceilings with openings for stairs and services.
Intelligent stair objects for straight, L-shaped, and U-shaped configurations. Set tread depth, riser height, width, and landing dimensions. 2D plan symbol and 3D geometry generated automatically.
Every AEC object exists in both 2D and 3D. Work in plan view to lay out rooms and the 3D model builds itself. Generate elevations and sections from the 3D model. Present to clients in full perspective renders.
Standard geometry, blocks, layers, linetypes, and xrefs transfer cleanly in both directions with colleagues on AutoCAD or AutoCAD Architecture. progeCAD's AEC objects are its own — not interchangeable with AutoCAD Architecture's AEC entities.
Note on AutoCAD Architecture files: When you open a drawing created in AutoCAD Architecture, its AEC entities — walls, doors, windows — appear as proxy objects in progeCAD, not as live editable AEC objects. Proxies can be exploded to recover the underlying geometry, but once exploded the drawing can no longer round-trip back to AutoCAD Architecture with intelligent AEC behaviour intact. If your team works actively in AutoCAD Architecture, plan for a one-way workflow.
Intelligent walls, doors, windows, stairs, roofs, and slabs — all included in the progeCAD Professional license. AutoCAD charges separately for Architecture; progeCAD doesn't.
What does the AEC Architectural Module include?
The AEC Architectural Module is included in every progeCAD Professional license at no extra cost. It adds intelligent building objects on top of the full AutoCAD-compatible architectural CAD software platform: walls that clean up at corners and T-junctions, doors and windows that cut their own openings, roofs generated from wall footprints, slabs, and stairs. It also supports Revit and IFC import directly. A perpetual license is $540 — compared to $2,095/year for AutoCAD Architecture.
Is the AEC Architectural module an extra purchase?
No. Intelligent AEC building objects — walls that clean up at corners and T-junctions, doors and windows that cut their own openings, roofs generated from wall footprints, slabs and stairs — are included in every progeCAD Professional license at no additional cost. Autodesk sells Architecture as a separate specialized toolset; progeCAD does not charge separately for it.
Can the AEC Architectural Module open drawings created in AutoCAD Architecture?
Yes, but with one important limitation worth planning around. Standard geometry, blocks, layers, linetypes, and XREFs transfer cleanly in both directions. However, AutoCAD Architecture's own AEC entities — its walls, doors, and windows — appear in progeCAD as proxy objects rather than live editable AEC objects. Proxies can be exploded to recover the underlying geometry, but once exploded the drawing can no longer round-trip back to AutoCAD Architecture with intelligent AEC behaviour intact. If your team works actively in AutoCAD Architecture, plan for a one-way workflow.
Can the AEC Architectural Module import Revit and IFC models?
Yes. The AEC Architectural Module supports both import and attach for Revit (.rvt, .rfa) and IFC files. Use Import to convert the model into editable geometry you can work with directly — extract elements, flatten to 2D documentation, or place on layers by category. Use Attach to reference the model as an underlay beneath your drawing without converting it. Either way, this is BIM reference rather than full parametric BIM authoring.
